Forming and baking

Funny Cake Machine 2000, electrical

the machine serves for dosing of dough and filling into the moulds,                    forming and baking of sponge dough products

-dough : sponge dough

-filling :  termostable

-construction: stainless steel

-two hoppers for  dough – the machine allows to produce two colour products

Machine type:  Funny Cake 2000

Baking molds:  26 molds, 5 characters: bear, squirrel, rabbit, turtle, hippo

Baking time:  2,5-3 min

Final product weight: 10 – 15 grams

Filling weight: 3 – 6 grams

Machine length: 3650 mm

Width: 1100 mm

Height: 1440 mm

Weight: 1300 kg

Capacity: 2000 pieces/hour,  30 kg/hour

Energy: Electricity

Electricity consumption: 15 kW

Electricity connection: 3N PE 50Hz, 230/400V/TN-S

 Conveyor:   Straight, belt conveyor

Conveyor length:  6050 mm

Coneyor height:  800-900 mm

Belt width:   570 mm

Cooling length:   4500 mm

Width of the tunnel:   1200 mm

Height of the tunnel:   1900-2000mm

Belt:    Ammeraal Beltech

Electricity:   3N PE 50Hz, 230/400V, TN-S

Input:   5,5 kVA

Protection:   IP 42

Shortest cooling time:   40 seconds

Longest cooling time:   11 minutes

Cooling

Cooling tunnel CHTD1

-the tunnel serves for cooling of the finished products before packaging

Packaging

Vertical packaging machine HBV5A incl. accessories (infeed conveyor and short outfeed conveyor for packed products)

-the machine serves for packaging of the products produced by Funny Cake 2000 machine into bags, e.g. 5 pieces per bag

Sizes (without dosing equipment), h x w x l:  1700 x 910 x1370 mm

Weight (without dosing equipment):  350 kg

Maximal width of the packaging material:  480mm

Maximal width of the bag:  300mm

Capacity (depends on the packaging material):  up to 40 strokes/min.

Installed input:   2,5kVA

Electrical connection:   3N PE 50Hz, 230/400V/TN-S

Trolleys, 3 pieces

-decks amount:              15

-sizes (h x l x w):             192 x 73 x 67 cm
